AK6

Product Code : AK6

Car Speed	Capacity	Pulley Size	Power	In	Pole	Rev	Torque
Suspension Type: 2:1 Static Load: 7000 KG
0,63 m/s	1250 KG	400x7x10mm	5,4	15 A	20P 10 Hz	60	852
0,63 m/s	1600 KG	320x10x8mm	7	17,5 A	20P 12,53Hz	75	872
1,00 m/s	1250 KG	400x7x10mm	8,6	23 A	20P 16Hz	96	852
1,00 m/s	1600 KG	320x10x8mm	11	28 A	20P 20Hz	120	872
1,60 m/s	1250 KG	400x7x10mm	13,7	32 A	20P 25,5Hz	153	852
1,60 m/s	1600 KG	320x10x8mm	17,5	45 A	20P 31.83Hz	191	872
2,00 m/s	1250 KG	400x7x10mm	17,1	40 A	20P 31,83Hz	191	852
2,00 m/s	1600 KG	320x10x8mm	22	52 A	20P 39,8Hz	239	872
2,50 m/s	1250 KG	400x7x10mm	21,3	50 A	20P 39.8Hz	239	852
2,50 m/s	1600 KG	320x10x8mm	27,3	64 A	20P 49.74Hz	298	872
