Product Code : ZF 112 YAN YAYAKLI
Technical Details
| Product Type | Suspension Type | Pulley Size | Static Load | Car Speed | Capacity | Ratio |
| ZF 112 11,00 Kw | 1:1 | 580*9*10 | 9000 KG | 1,00 m/s | 1840 KG | 46/1 |
| 700*7*10 | 9000 KG | 1,20 m/s | 1520 KG | 46/1 | ||
| 580*6*10 | 9000 KG | 1,60 m/s | 1200 KG | 55/2 | ||
| 700*6*10 | 9000 KG | 2,00 m/s | 960 KG | 55/2 | ||
| 580*5*10 | 9000 KG | 2,40 m/s | 750 KG | 51/3 | ||
| 700*5*10 | 9000 KG | 3,20 m/s | 640 KG | 51/3 | ||
| ZF 112 15,00 Kw | 1:1 | 580*8*12 | 9000 KG | 1,00 m/s | 2480 KG | 46/1 |
| 700*10*10 | 9000 KG | 1,20 m/s | 2080 KG | 46/1 | ||
| 580*8*10 | 9000 KG | 1,60 m/s | 1650 KG | 55/2 | ||
| 700*6*10 | 9000 KG | 2,00 m/s | 1360 KG | 55/2 | ||
| 580*6*10 | 9000 KG | 2,40 m/s | 1050 KG | 51/3 | ||
| 700*6*10 | 9000 KG | 3,20 m/s | 880 KG | 51/3 | ||
| ZF 112 17,50 KW | 1:1 | 580*9*12 | 9000 KG | 1,00 m/s | 2925 KG | 46/1 |
| 700*8*12 | 9000 KG | 1,20 m/s | 2400 KG | 46/1 | ||
| 580*9*10 | 9000 KG | 1,60 m/s | 1920 KG | 55/2 | ||
| 700*8*10 | 9000 KG | 2,00 m/s | 1520 KG | 55/2 | ||
| 580*6*10 | 9000 KG | 2,40 m/s | 1200 KG | 51/3 | ||
| 700*6*10 | 9000 KG | 3,20 m/s | 1040 KG | 51/3 | ||
| ZF 112 18,50 Kw | 1:1 | 580*10*12 | 9000 KG | 1,00 m/s | 3075 KG | 46/1 |
| 700*8*12 | 9000 KG | 1,20 m/s | 2560 KG | 46/1 | ||
| 580*10*10 | 9000 KG | 1,60 m/s | 2025 KG | 55/2 | ||
| 700*8*10 | 9000 KG | 2,00 m/s | 1680 KG | 55/2 | ||
| 580*6*10 | 9000 KG | 2,40 m/s | 1280 KG | 51/3 | ||
| 700*6*10 | 9000 KG | 3,20 m/s | 1050 KG | 51/3 | ||
| ZF 112 22,00 Kw | 1:1 | 580*9*14 | 9000 KG | 1,00 m/s | 3680 KG | 46/1 |
| 700*10*12 | 9000 KG | 1,20 m/s | 3040 KG | 46/1 | ||
| 580*8*12 | 9000 KG | 1,60 m/s | 2400 KG | 55/2 | ||
| 700*9*10 | 9000 KG | 2,00 m/s | 2000 KG | 55/2 | ||
| 580*8*10 | 9000 KG | 2,40 m/s | 1575 KG | 51/3 | ||
| 700*6*10 | 9000 KG | 3,20 m/s | 1280 KG | 51/3 |
